ELISA READER
Supplier : Ctk Biotech
Catalog# : ADX-110
Description
FEATURES
- Reliable, accurate, cost-effective.
- Flexible programming to meet your needs.
- Accommodates different microplate geometries.
- Variable speed and duration on plate shaker Ability to read plate within seconds.
- Digital light control with unique circuit for long lamp life.
- Storage of calibration curves.
- Storage of plate results.
- Single Dual and wavelength readings.
-
Preferred by lab technician worldwide.
Specifications
TECHNICAL SPECIFICATIONS
- 6” Graphics LCD, Negative Blue, STN
- Photometric Accuracy – ± 2% or 0.007 whichever is higher, from 0 to 1.5 A ± 3% from 1.5 A to 3.5 A
- Linear Measurement Range – 0.000 to 3.500 Absorbance units (A)
- Plate Carrier Movement – Precisely through the stepper motor
- Analysis Mode: Absorbance (normal & differential) Cut – off Multi – standard?sorbance, Single standard, Uptake Kinetic,
- RS232 Serial Port / USB – 9600 baud, 8 data, 1 stop, no parity bits / USB
- Graphical Representation on Printer
- Drift –Precisely through the stepper motor
- TOUCH PANEL / KEYPAD Filters: Type of
- Filter – High quality narrow band Interference
- Wave Length – 405nm, 450nm, 492nm, 630 nm & four optional
- Half Bandwidth – 10 nm ± 2nm
- Automatic by stepper motor
- Curve Plotting – Graphical representation on printer
- Optical Measurement : 8 Channel
- Built in Thermal Printer 52 columns
- Battery back up for 250 tests and more than 2500 results
FEATURES
- Reliable, accurate, cost-effective.
- Flexible programming to meet your needs.
- Accommodates different microplate geometries.
- Variable speed and duration on plate shaker Ability to read plate within seconds.
- Digital light control with unique circuit for long lamp life.
- Storage of calibration curves.
- Storage of plate results.
- Single Dual and wavelength readings.
-
Preferred by lab technician worldwide.
TECHNICAL SPECIFICATIONS
- 6” Graphics LCD, Negative Blue, STN
- Photometric Accuracy – ± 2% or 0.007 whichever is higher, from 0 to 1.5 A ± 3% from 1.5 A to 3.5 A
- Linear Measurement Range – 0.000 to 3.500 Absorbance units (A)
- Plate Carrier Movement – Precisely through the stepper motor
- Analysis Mode: Absorbance (normal & differential) Cut – off Multi – standard?sorbance, Single standard, Uptake Kinetic,
- RS232 Serial Port / USB – 9600 baud, 8 data, 1 stop, no parity bits / USB
- Graphical Representation on Printer
- Drift –Precisely through the stepper motor
- TOUCH PANEL / KEYPAD Filters: Type of
- Filter – High quality narrow band Interference
- Wave Length – 405nm, 450nm, 492nm, 630 nm & four optional
- Half Bandwidth – 10 nm ± 2nm
- Automatic by stepper motor
- Curve Plotting – Graphical representation on printer
- Optical Measurement : 8 Channel
- Built in Thermal Printer 52 columns
- Battery back up for 250 tests and more than 2500 results
